Chapter 2 Huru Frameset ( rim brake ) - Aqua UD

AQUA + UD ( KORIO )
Limited Edition

If the joy of being in the zone and scaling gradients that pushes you to the limit is what stirs you, then the HURU is the perfect tool for the job. HURU means “feather” in Maori and its classic contours cleverly disguise the engineering needed to develop a high-performance lightweight frame.

As the saying goes, “what goes up must come down”, so whilst the HURU has you covered for the former, the HURU also excels in the latter so that you can descend confidently on a frame platform that has cornering dexterity that matches its climbing prowess.

The pencil-thin Seatstays that dampen road vibrations is beautifully merged into the Seattube and Toptube junction that supports our lightweight TUMU 27.2mm seatpost.

Available in Rim (Direct Mount) and Disc versions, and using over 300 unique pieces of Pre-Preg Carbon Fibre carefully laid into stainless steel moulds by hand, the HURU is the ultimate alpine machine.

SPECIFICATIONS:

Carbon:Toray® T700, T800 & 3K Directional Carbon
Frame 5 Sizes: XS, S, M, L & XL
Fork Rakes (XS, S (53mm offset) and M, L, XL (43mm offset)
Frame Weight:885g Size M +/- 3%
Fork Weight:389g Uncut +/- 3%
Seatpost Weight:219g +/- 3%
Handlebar/Stem (MANA):Not included
Headset:CHAPTER2 1-1/8”
BB:Press Fit BB86.5
Electronic Shifting:SHIMANO® Di2, SRAM® eTAP & Campagnolo® EPS compatible
Battery Type:Di2 SM-BTR-2 or BT-DN300 and EPS V3 Battery Compatible
Tire Clearance:28mm
Brake Type:Direct Mount Type
Disc Thru-Axle Spec:Flat Mount, FR 12x100mm, RR 12x142mm, E-Thru M12x1.5mm
Safety Standard:EN ISO 4210:2014
UCI Accreditation:UCI Approved
